YRKK450-4W IC616 IP55 outdoor 710 kW 6 kV High Voltage Wound Rotor Slip Ring Motor with Liquid Resistor Starter was shipped for Iran Feb.8

Update time：08th,Feb,2021

1 PC YRKK450-4W outdoor installation 710 kW 6 kV High Voltage Wound Rotor Slip Ring Motor and 1 PC TRQ-710 kW Liquid Resistor Starter Cabinet were shipped for Bandar Abbas, Iran on Feb. 8th, 2021.

Main Parameter for YRKK450-4W 710 kW 6 kV High Voltage Wound Rotor Slip Ring Motor:
Type: YRKK450-4W                             Power factor: 0.85                                      Rated power: 710 kW
Mounting: IMB3                                   Duty: S1 continuous                                   Insulation class F
Stator voltage: 6000 V                         Stator current: 84.9 A                                Stator connection: Y star
Rotor voltage: 811 V                            Rotor current: 530 A                                   Rotor connection: Y star
Cooling type: IC616                             Enclosure protection: IP55 outdoor           Rated speed: 1486 r/min
Bearing brand: FAG                             Rated frequency: 50 Hz
With 8 pcs PT100 in windings and bearings.
With 220 V 50 Hz single phase anti-condensation space heater

Nameplate for YRKK450-4W 710 kW 6 kV High Voltage Wound Rotor Slip Ring Motor

Nameplate for Liquid Resistor Starter Cabinet

Liquid Resistor Starter Cabinet
