VHS Series IEC Vertical Hollow Shaft Motor
Payment Terms: 30% in advance, balance by T/T or L/C at sight
Minimum Order: 1 Piece
Package: plywood box
Brand Name: ELE
Standard IEC
Protection IP23, IP54, IP55
Insulation: Normal class F
Duty: S1
Ambient condition: Normal Temperature ≤40oC, Normal Altitude ≤1000m

  •  · Features and application
    VHS Series IEC standard vertical hollow shaft motor, also called as VHS motor, the latest products of our factory, is three phase squirrel cage induction motors, especially for driving vertical deep well turbine pump.
    The motors are of high efficiency, high starting torque, quiet-running, low vibration, low temperature rise, can sustain heavy axial thrust load, have compact and reliable structure with easy maintenance etc. The rated output grades conform to the IEC standard.
    After being fitted with vertical pumps, the motors are widely used in pumping underground water in mines, city, farm and factories etc. The degree of protection is weather-protected type1 (drip-proof).

         · Performance

    Type

    Rated Output

    Rated Current

    Rated Voltage

    Rated Frequency

    Synchronous Speed

    Efficiency

    Power Factor

     hp/kw

     A

     V

     Hz

     r/min

     %



    VHS132-1-2

    7.5/5.5

    11/10.8

    380

    50/60

    3000/3600

    83.8

    0.88

    VHS132-2-2

    10/7.5

    14.4/14.5

    380

    50/60

    3000/3600

    84.8

    0.88

    VHS160-1-2

    15/11

    22.5/22

    380

    50/60

    3000/3600

    84.5

    0.88

    VHS160-2-2

    20/15

    30

    380

    50/60

    3000/3600

    85.5

    0.88

    VHS160-1-4

    15/11

    23/22.5

    380

    50/60

    1500/1800

    86.5

    0.85

    VHS160-2-4

    20/15

    30

    380

    50/60

    1500/1800

    87.5

    0.86

    VHS180-1-2

    25/18.5

    36

    380

    50/60

    3000/3600

    87

    0.88

    VHS180-2-2

    30/22

    43/42.5

    380

    50/60

    3000/3600

    87.5

    0.88

    VHS180-1-4

    25/18.5

    37

    380

    50/60

    1500/1800

    88

    0.86

    VHS180-2-4

    30/22

    43.5/43

    380

    50/60

    1500/1800

    88.5

    0.86

    VHS200-1-2

    40/30

    58

    380

    50/60

    3000/3600

    88

    0.88

    VHS200-2-2

    50/37

    70.5/70

    380

    50/60

    3000/3600

    88.5

    0.88

    VHS200-1-4

    40/30

    58/58.5

    380

    50/60

    1500/1800

    89.5

    0.87

    VHS200-2-4

    50/37

    72/71

    380

    50/60

    1500/1800

    90

    0.87

    VHS200-3-4

    60/45

    85/85.5

    380

    50/60

    1500/1800

    90.5

    0.87

    VHS250-1-4

    75/55

    105.5/103.5

    380

    50/60

    1500/1800

    91

    0.88

    VHS250-2-4

    100/75

    139.5/140

    380

    50/60

    1500/1800

    91.5

    0.88

    VHS250-3-4

    125/90

    173/167.5

    380

    50/60

    1500/1800

    91.5

    0.88

    VHS280-1-4

    150/110

    205.5/202

    380

    50/60

    1500/1800

    92

    0.88

    VHS280-2-4

    175/132

    238/241

    380

    50/60

    1500/1800

    92.5

    0.88

    VHS280-3-4

    200/150

    275/276

    380

    50/60

    1500/1800

    92.5

    0.88

    VHS280-4-4

    250/185

    348/345

    380

    50/60

    1500/1800

    92.5

    0.88

    VHS280-5-4

    270/200

    374/371

    380

    50/60

    1500/1800

    93

    0.88

    VHS280-6-4

    300/220

    415/408

    380

    50/60

    1500/1800

    93

    0.88

    VHS315-1-4

    250/185

    348/345

    380

    50/60

    1500/1800

    93

    0.88

    VHS315-2-4

    270/200

    374/371

    380

    50/60

    1500/1800

    93

    0.88

    VHS315-3-4

    300/220

    415/408

    380

    50/60

    1500/1800

    93

    0.88

    VHS315-4-4

    350/260

    484.5/480

    380

    50/60

    1500/1800

    93.5

    0.88

    VHS355-1-4

    400/300

    554

    380

    50/60

    1500/1800

    93.5

    0.88

    VHS355-2-4

    450/335

    623/618

    380

    50/60

    1500/1800

    93.5

    0.88

    VHS355-3-4

    500/375

    689

    380

    50/60

    1500/1800

    94

    0.88

    VHS355-4-4

    600/450

    826

    380

    50/60

    1500/1800

    94

    0.88


  • Type

    Rated Output

    Rated Current

    Rated Voltage

    Rated Frequency

    Synchronous Speed

    Efficiency

    Power Factor

     hp/kw

     A

     V

     Hz

     r/min

     %



    VHS132-1-2

    7.5/5.5

    11/10.8

    380

    50/60

    3000/3600

    83.8

    0.88

    VHS132-2-2

    10/7.5

    14.4/14.5

    380

    50/60

    3000/3600

    84.8

    0.88

    VHS160-1-2

    15/11

    22.5/22

    380

    50/60

    3000/3600

    84.5

    0.88

    VHS160-2-2

    20/15

    30

    380

    50/60

    3000/3600

    85.5

    0.88

    VHS160-1-4

    15/11

    23/22.5

    380

    50/60

    1500/1800

    86.5

    0.85

    VHS160-2-4

    20/15

    30

    380

    50/60

    1500/1800

    87.5

    0.86

    VHS180-1-2

    25/18.5

    36

    380

    50/60

    3000/3600

    87

    0.88

    VHS180-2-2

    30/22

    43/42.5

    380

    50/60

    3000/3600

    87.5

    0.88

    VHS180-1-4

    25/18.5

    37

    380

    50/60

    1500/1800

    88

    0.86

    VHS180-2-4

    30/22

    43.5/43

    380

    50/60

    1500/1800

    88.5

    0.86

    VHS200-1-2

    40/30

    58

    380

    50/60

    3000/3600

    88

    0.88

    VHS200-2-2

    50/37

    70.5/70

    380

    50/60

    3000/3600

    88.5

    0.88

    VHS200-1-4

    40/30

    58/58.5

    380

    50/60

    1500/1800

    89.5

    0.87

    VHS200-2-4

    50/37

    72/71

    380

    50/60

    1500/1800

    90

    0.87

    VHS200-3-4

    60/45

    85/85.5

    380

    50/60

    1500/1800

    90.5

    0.87

    VHS250-1-4

    75/55

    105.5/103.5

    380

    50/60

    1500/1800

    91

    0.88

    VHS250-2-4

    100/75

    139.5/140

    380

    50/60

    1500/1800

    91.5

    0.88

    VHS250-3-4

    125/90

    173/167.5

    380

    50/60

    1500/1800

    91.5

    0.88

    VHS280-1-4

    150/110

    205.5/202

    380

    50/60

    1500/1800

    92

    0.88

    VHS280-2-4

    175/132

    238/241

    380

    50/60

    1500/1800

    92.5

    0.88

    VHS280-3-4

    200/150

    275/276

    380

    50/60

    1500/1800

    92.5

    0.88

    VHS280-4-4

    250/185

    348/345

    380

    50/60

    1500/1800

    92.5

    0.88

    VHS280-5-4

    270/200

    374/371

    380

    50/60

    1500/1800

    93

    0.88

    VHS280-6-4

    300/220

    415/408

    380

    50/60

    1500/1800

    93

    0.88

    VHS315-1-4

    250/185

    348/345

    380

    50/60

    1500/1800

    93

    0.88

    VHS315-2-4

    270/200

    374/371

    380

    50/60

    1500/1800

    93

    0.88

    VHS315-3-4

    300/220

    415/408

    380

    50/60

    1500/1800

    93

    0.88

    VHS315-4-4

    350/260

    484.5/480

    380

    50/60

    1500/1800

    93.5

    0.88

    VHS355-1-4

    400/300

    554

    380

    50/60

    1500/1800

    93.5

    0.88

    VHS355-2-4

    450/335

    623/618

    380

    50/60

    1500/1800

    93.5

    0.88

    VHS355-3-4

    500/375

    689

    380

    50/60

    1500/1800

    94

    0.88

    VHS355-4-4

    600/450

    826

    380

    50/60

    1500/1800

    94

    0.88
