20T induction furnace with 6.3Mva transformers shipped for Abbas on Aug.29,2012

Update time：28th,Aug,2012

1 set 20ton 10Mw medium frequency induction melting furnace with matched 2pcs of 6300Kva rectifier transformer were shipped for Bandar Abbas Iran on Aug. 29th. 2012.

Induction Furnace:

Model: GWG-20-10000/0.25J                         Rated Capacity: 20Ton                        Rated Power: 10000Kw

Working Frequency: 250Hz                            Pulse: 24                                             Power input: 1000V/50Hz

Rectifier Transfomrer

Model: ZSSP-6300/33-1.0x2.                          Rated capacity: 6300Kva                     Primary voltage: 33Kv

Secondary Voltage: 1000V                             Cooling method: Oil Force Water Force (OFWF)

Quantity: 2pcs

Power Supply Cabinets and Capacitor bank in 40HQ container

Two Layers Capacitor Bank

20Ton Furnace Body loading on 20FR Container

Front side of 20ton induction furnace

20ton induction furnace in customs inspection place

2pcs of 20ton induction furnace body

Hydraulic station and capacitor bank in 40HQ container

6300kva rectifier transformer in 40HQ container

6300kva rectifier transformer in warehouse
